Immergas Victrix Zeus 32 kW Boiler with LPG Condensing Boiler Code 3.028382 - Complete with Flue Gas Exhaust Kit - NEW ERP

Technical Features

Model

Product Code: 3.028382
Type: Wall-mounted condensing boiler WITH 45 LITRE BOILER

Product Plus

• HYDROGEN READY 20%

Energy efficiency

• Heating energy class: A

• Energy class in sanitary / Load profile: A / XL

Performance

• Useful heating power: 28 kW

• Useful domestic hot water power: 32 kW

Typology

• With integrated 45 L boiler

Modulation field

• 17 – 100%

Hot water production (Δt 30 °C)

• Specific flow rate: 16.0 l/min

• Continuous duty: 15.1 l/min

Dimensions and Weight

• Dimensions (HxWxD): 900 x 580 x 410 mm

Energy Efficiency

• Maximum nominal heat output in domestic hot water: 33.1 kW
• Maximum nominal heat output in heating mode: 29.0 kW
• Minimum nominal heat output: 4.3 kW
• Maximum useful thermal power in domestic hot water: 32.0 kW
• Maximum useful thermal power in heating: 28.0 kW
• Minimum useful thermal power: 4.0 kW
• Thermal efficiency at 100% Pn (80/60 °C): 96.6 %
• Thermal efficiency at 100% Pn (40/30 °C): 106.3 %
• Useful thermal efficiency at 30% of the nominal load (with return temperature of 30 °C): 107.8 %
• Gas flow rate to the burner (methane) max/min: 3.50/0.46m3 /h*
• Weighted CO: 22 mg/kWh
• Nox Class: 6
• Available intake/exhaust pressure (Min. - Max. flow rate): 4/223 Pa
• Specific flow rate (∆t 30 °C): 16.0 l/min
• Heating expansion vessel capacity: 10.0 litres
• Sanitary expansion vessel capacity: 2.0 litres
• Electrical protection rating: 5D IPX
• Boiler weight full of water (empty): 118.6 (65.5) kg

General Features

VICTRIX ZEUS

SAVINGS
Tax relief: You can take advantage of current tax deductions.

Low consumption: the low consumption circulator allows for significant electricity savings.

COMFORT
Kettle: 45-liter stainless steel. The kettle's capacity and excellent temperature regulation ensure maximum comfort.

Ease of use: practical knobs and a backlit display allow you to easily manage and view the boiler settings.

Thermoregulators: optional. They improve comfort and increase energy savings.

ENVIRONMENTAL COMPATIBILITY
Eco-friendly technology: complies with the European ErP and ELD Directives, allowing you to achieve high energy efficiency classes in heating and hot water production.

Ecological class 5 (European standards UNI 297 and 483): the best for reduced nitrogen oxide (NOX) emissions.

INSTALLATION
High flexibility: approved for indoor and outdoor use in partially protected areas. IPX4D electrical protection. Standard antifreeze protection down to -5°C.

Compactness: easy to install in any environment even in case of replacement.
