Samsung DW60DG770B00U1 14-place, Class B, fully integrated dishwasher

Samsung DW60DG770B00U1

• Positioning of the appliance: Fully concealed

• Size: Maximum size (60 cm)

• Control type: Touch

• Number of seats: 14 seats

• Energy efficiency class: B

• Water consumption per cycle: 9.4 L

• Width: 595 mm, Depth: 552 mm, Height: 815 mm.

Technical Features

COD: DW60DG770B00U1_T

EAN: 8806095680828

Design

• Installation type: Fully concealed

• Size: Standard 60 cm

• Door color: Not applicable (panelable)

• Built-in display: Yes

• Control type: Touch

• Integrated water softener: Yes

• Upper basket adjustment: Yes

• Cutlery compartment type: Basket

• Floor indicator light: Yes

Dimensions and Weight

• Width: 595 mm

• Depth: 552 mm

• Height: 815 mm

• Weight: 40.5 kg

• Maximum weight of custom panel: 9 kg

• Built-in dimensions (W x D x H): 600 × 575 × 820–900 mm

Energy Management

• Energy efficiency class: B

• Water consumption per cycle: 9.4 L

• Energy consumption per cycle: 0.644 kWh

• Consumption per 100 cycles: 64 kWh

• EEI Index: 37.9

• Circulation motor power: 53 W

• Heating resistance power: 2100 W

• Drain pump power: 35 W

• Power consumption in “off” mode: 0.48 W

• Voltage/Frequency: 220–240 V / 50 Hz

• Energy Scale: From A to G

Performance

• Number of seats: 14

• Number of washing programs: 9

• Noise emission class: B

• Noise emission: 43 dB

• Eco cycle duration: 249 min

• Special programs: Auto, Delicate, Eco, Express, Extra Quiet, Intensive, Prewash

• Delayed departure: Yes

• Half load: Yes

• Drying system: Not specified

• Aquastop system: Yes

• Water overflow protection: Yes

Connectivity

• Wi-Fi controlled: Yes

• App control: SmartThings

• Remote smartphone support: Yes

General Features

Improved energy efficiency

Maximum washing and drying efficiency

The dishwasher consumes less energy but cleans and dries dishes effectively. According to the new European energy label, it has a high energy efficiency rating of Class B. Thanks to the innovative all-in-one drain pan, it consumes less energy and only 9.4 liters of water , always ensuring excellent washing performance.

More power for your washes

WaterJet Clean™

Improved washing results with the new WaterJet Clean™, which ensures a deep 360° clean thanks to the two arms that rotate in opposite directions generating two powerful jets of water. The result? A perfect clean even for the most encrusted pans and dishes.

Quiet and silent house

Extra quietness

For a quieter home. The dishwasher runs smoother and quieter thanks to its inverter motor. It also features an Extra Silence program that washes a little more slowly, but produces 2 decibels less noise than the ECO program. The noise emitted is even lower than that of a library.

At a glance

Warning light

Check at a glance if your dishwasher is running! The indicator light on the bottom of the appliance projects a beam of white light onto the floor when a wash cycle is in progress. Easy to see even from a distance, it turns off as soon as your dishes are clean and ready to be unloaded, without having to check in person!

Automatic steam release and drying

Auto Open Door

The Auto Open function ensures dishes are always clean and sparkling. Once the rinsing and drying process is complete, the door automatically opens 10 cm to expel steam, ensuring better and faster results than traditional methods, especially for plastic and small items.

Flexible space management

Flexible load

Load plates, glasses, and cups of various shapes and sizes with ease: the middle rack can be adjusted to 3 different positions using a lever and also features a cup holder. Equipped with foldable prongs, the lower rack is perfect for safely storing plates and bowls, while larger items can be stored on the bottom.

Interior sanitized without detergents

Dishwasher care

Maintain hygiene inside your dishwasher while respecting the environment. With the Machine Care function, you can clean it with the simple press of a button: the program removes dirt and odor-causing bacteria using only water, without adding harsh detergents. And it automatically reminds you when to clean.

Prevent spill damage

Water Stop

The Aqua Stop safety feature helps prevent unexpected water damage. If it detects small traces of water, it cuts off the water supply and electrical connections to stop the dishwasher from operating. This prevents electric shocks and costly water damage.

Smart cleaning

SmartThings

Discover a more efficient way to use your dishwasher. With the SmartThings app, you can control settings remotely and start the cycle during off-peak energy or carbon-neutral periods. Furthermore, the app suggests the most suitable programs based on your cooking and food preparation habits, helping you reduce energy consumption, optimize spare parts management, and troubleshoot any issues.
