Vaillant OutsideMag 158/1 RT 15 Lt Low Nox Methane Gas Water Heater Code 0010022467 - For Outdoor Use

Technical Features

Model

Vaillant OutsideMag 158/1 RT 15 Lt Low Nox Methane Gas Water Heater for Outdoor Use

Product Code: 0010022467

Energy Efficiency

Hot water flow rate (ΔT= 25 K) l/min 15.0
Hot water flow rate (ΔT= 35 K) l/min 10.7
Hot water flow rate (ΔT= 50 K) l/min 7.5
Max. water temperature °C 60
Min. water temperature °C 38
Maximum heat output (referred to the calorific value Hi) kW 29.1
Minimum heat output (Qmin.) kW 5.6
Maximum thermal power (Pmax.) kW 26.2
Minimum thermal power (Pmin.) kW 5
Power range kW 8.5
Maximum permissible water pressure Pw max. bar 10.0
Minimum permissible water pressure Pw min. bar 0.14
Smoke temperature at maximum heat output °C 140
Smoke temperature at minimum thermal power °C 50

Dimensions

Dimensions HxWxD mm; 580x412x181

General Features

OUTSIDEMAG LOW NOX



outsideMAG are forced draft outdoor water heaters with low NOx emissions (class 6) for the production of domestic hot water.

The outsideMAG offering is very flexible and covers the following sanitary production flow rates: 12, 15 and 17 litres/minute with methane and LPG models.

outsideMAG outdoor water heaters are equipped with a remote control to manage your comfort from the comfort of your home.

Hydraulic connections are also included.

Vaillant has designed this new range to operate outside the home, increasing protection down to -25°C as standard.

They are very simple to install and do not require connections to the flue as they have a facade exhaust already integrated into the front panel (Type A approval).

An innovative combustion system that expands the modulation range and two water temperature control probes at the inlet and outlet guarantee perfect temperature stability.

A solar kit as an accessory also allows you to preheat the incoming water and further reduce gas consumption.
